ROC-RK3588-RT ARM Single Board Computer

ROC-RK3588J-RT

4G RAM+64G ROM
$579.00
$579.00
Skip to product information
ROC-RK3588-RT ARM Single Board Computer
  • ROC-RK3588-RT ARM Single Board Computer
  • ROC-RK3588-RT ARM Single Board Computer
  • ROC-RK3588-RT ARM Single Board Computer
  • ROC-RK3588-RT ARM Single Board Computer
  • ROC-RK3588-RT ARM Single Board Computer
ROC-RK3588J-RT

ROC-RK3588J-RT

$579.00
$579.00
Shipping calculated at checkout.
Storage:4G RAM+64G ROM

Industrial RK3588J SBC with a 6 TOPS NPU, 2.5GbE and dual Gigabit Ethernet for edge AI and network gateways.
  • American Express
  • Apple Pay
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Union Pay
  • Visa

Specifications

ROC-RK3588J-RT
Basic Specifications SOC

Rockchip RK3588J
CPU

Octa-core 64-bit(4×Cortex-A76+4×Cortex-A55), Up to 1.6GHz
GPU

ARM Mali-G610 MP4 Quad-core GPU, support OpenGL ES3.2/OpenCL 2.2/Vulkan1.1, 450 GFLOPS
NPU

The computing power is up to 6TOPs (INT8), supports INT4/INT8/INT16 hybrid computing, and can be based on TensorFlow/MXNet/PyTorch/Caffe and other series of frameworks
Decoding/ Encoding

Hardware Decoding: 8K@60fps VP9/AVS2, 8K@30fps H.264 AVC/MVC, 4K@60fps AV1, 1080P@60fps MPEG-2/-1/VC-1/VP8

Hardware Encoding: 8K@30fps H.264
RAM

4GB/8GB/16GB/32GB LPDDR4/LPDDR4x
Storage

32GB/64GB/128GB eMMC
Storage expansion

1 × M.2 SATA/PCIe NVMe SSD (2242), 1 × TF Card
OS

Android, Linux OS, OpenWRT
Power

DC 12V (5.5 × 2.1mm, support 9V~36V wide voltage input)
Power consumption

Max: 13.2W(12V/1100mA)

Normal: 3W(12V/250mA)

Min: 0.36W(12V/30mA)
Dimension

108.48mm × 74.98mm × 22.80mm
Weight

≈94g
Environment

Operating Temperature: -40℃～85℃,

Operating Humidity: 10%～90%RH(non-condensing)
Interface Specifications Ethernet

2 × 1000M bps Ethernet

1 × 2.5G bps Ethernet

WAN / LAN Customizable
Wireless network

The WiFi/Bluetooth module can be expanded through the M.2 E-KEY (2230), supporting WiFi6 and Bluetooth5.0
Video output

1 × HDMI2.1 (8K@60Hz), 1 × HDMI2.0 (4K@60Hz), 1 × DP1.4 (8K@30Hz, output via Type-C port)
Audio output

1 × 3.5mm Audio jack (Support MIC recording, American standard CTIA)
USB

1 × USB3.0 (Max: 1A), 1 × USB2.0 (Max: 500mA), 1 × Type-C (USB3.0 OTG/DP1.4)
Debug UART

1 × Debug (Debugging Serial Port, 3Pin-2mm)
Button

1 × Recovery, 1 × Reset
Other interfaces

1 × BTB connector (2×30Pin/0.8PH), interfaces can be extracted：2×PCIe3.0(4Lanes) | 2×UART | 1×USB2.0 | 1×CAN | 1×SARADC | GPIO

Among them, the PCIe3.0 can be combined in a variety of ways:

1 × PCIe3.0 (4Lanes, RC or EP) or

1 × PCIe3.0 (2Lanes, RC or EP) + 1 × PCIe3.0 (2Lanes, RC) or

1 × PCIe3.0 (2Lanes, RC or EP) + 1 × PCIe3.0 (1Lane, RC) or

4 × PCIe3.0 (1Lane, RC)
