GS1-N2 AI Network Video Recorder

GS1-N2 AI Gateway Server

RK3576 (8G+64G) / 1688 (8G+32G)
$929.00
Sale price  $929.00 Regular price
Skip to product information
GS1-N2 AI Network Video Recorder

GS1-N2 AI Gateway Server

$929.00
Sale price  $929.00 Regular price
Taxes included. Shipping calculated at checkout.
Main Module:RK3576 (8G+64G)
Submodule:1688 (8G+32G)
Quantity
  • American Express
  • Apple Pay
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Union Pay
  • Visa
Brand Firefly
Availability 1 in stock

The Firefly GS1-N2 is a high-performance 1U edge AI server featuring a unique dual-core architecture that delivers up to 157 TOPS and 8K video decoding. With 10 Gigabit PoE ports and dual SATA bays, it provides a powerful, all-in-one solution for real-time video analytics in smart security, industrial vision, and IoT applications.

Feature

  • Dual-core Board Modular Architecture: It adopts a dual-core heterogeneous architecture, with one core responsible for video recording and the other for AI processing, supporting real-time inference of AI models. The two core modules work independently.
  • Built-in SAS/SATA Hard Drive Bays: It features two 3.5-inch/2.5-inch SAS/SATA drive bays, supporting SATA 3.0 HDD/SSD or PCIe NVMe SSD expansion, allowing the device to be easily expanded to terabyte-level capacity.
  • Supports Custom Event Detection: Supports custom event detection, such as motion detection, area intrusion detection, boundary crossing detection, object recognition, video occlusion detection, etc., and automatically alarms when an anomaly is detected.

Product Overview

Soc

RK3576 / RK3588 / BM1688 / Jetson Orin Nano / Jetson Orin NX

Npu

6TOPS~157TOPS

Storage expansion

1 × TF Card (The interface is unavailable when the main module is Jetson Orin Nano/Jetson Orin NX)

Power

280W AC power supply (Input: 100V AC~240V AC, 50Hz ~ 60Hz, 6A; Output 1: 12V DC, 5A; Output 2: 52V DC, 4.6A; Does not support hot-swapping)

Power consumption

Normal: 16W ~ 22W, Max: 55W ~ 68W

Video output

1 × VGA (Maximum resolution 1080P), 1 × HDMI2.0 (4K@60fps)

Video input

Supports up to 32 channels 1080P@30fps H.265/H.264 video inputs

Audio

1 × Audio input, 1 × Audio output

Dimension

490.0mm × 368.0mm × 44.4mm

Environment

Operating Temperature: 0ºC ~ 45ºC

Storage Temperature: -40ºC ~ 60ºC

Operating Humidity: 5% ~ 90%RH (non-condensing)

Internet

8 × Gigabit Ethernet (RJ45, support PSE function, can provide PoE power supply for terminal devices)

2 × LAN (RJ45/1000Mbps)

○ Upper LAN port supports PSE function, can providePoE power supply for terminal devices.

○ Lower LAN is management port (not available when main module is Jetson Orin Nano/Jetson Orin NX).

Support 2.4GHz/5GHz dual-band WiFi (Extended via M.2 E-KEY, multiplexed with SATA3.0)

Support IPv6, UPnP (Plug and Play), NTP (Network Timing), SADP (Automatic IP Address Search), DHCP (Automatic IP Address Acquisition) network protocols

Usb

3 × USB3.0

Other

1 × ALARM (10Pin-2.54mm, Lead-out: RS485, IO)

Sata pcie

● 3 × SATA3.0 (supports 3.5’’ or 2.5’’ SSD/HDD expansion)
○ SATA0: Shared with PCIe0. SATA0 is available only when the main module is Core-3588SJD4 AI /
Core-3576JD4. For other main modules, only PCIe0 is supported and SATA0 is unavailable.
○ SATA2, SATA3:
Independent, available only when the main module is Core-3588JD4.

● Choose one of the following functions:
○ 1 × SATA3.0 (SATA1, shared with PCIe; default function)
○ 1 × M.2 (PCIe1, shared with SATA1, M-KEY; supports PCIe NVMe 2280 SSD expansion) and 1 × M.2 (PCIe WiFi, shared with SATA1, E-KEY; supports WiFi expansion)

● 3 × M.2 (M-KEY, supports PCIe 2280 SSD expansion)
○ PCIe0: Shared with SATA0. SATA0 is available only when the main module is Core-3588SJD4 AI /
Core-3576JD4. For other main modules, only PCIe0 is supported and SATA0 is unavailable.
○ RES_PCIe: Available when the sub module is installed.
○ RES_PCIe2: Available only when the sub module is Core-3588JD4 / Jetson Orin Nano / Jetson Orin NX.

Product tutorials Click Here
