Brand Firefly
Availability 6 in stock


Soc

CV186AH
Cpu

Hexa-core 64-bit ARM Cortex-A53 @ 1.6GHz
Tpu

Built-in SOPHGO neural network acceleration engine TPU, computing power up to 7.2T@INT8, 12T@INT4, 1.5T@FP16/BF16
Npu

7.2TOPS
Vpu

Video decoding: H.264 decoding (maximum performance: 1920×1080@480fps or 8192×4320@30fps)
Video encoding: H.264 encoding (maximum performance: 1920×1080@300fps or 8192×4320@15fps)
Image codec: JPEG/MJPEG Baseline codec (JPEG codec: 1080P@480fps, maximum resolution 32768×32768)
Ram

4GB LPDDR4 (4GB/8GB optional)
Storage

32GB eMMC (32GB/64GB/128GB/256GB optional)
Storage expansion

1 × TF Card, 1 × M.2 (expandable M.2 NVME 2242/2260/2280 SSD),
1 × SATA3.0 (expandable SATA3.0 SSD)
Sata

1 × SATA3.0 (expandable SATA3.0 SSD)
Power

DC 12V (5.5mm × 2.1mm, support 9V~24V wide voltage input)
Audio output

1 × 3.5mm Audio jack (support MIC recording, American standard CTIA)
Os

Linux OS（Ubuntu）
Dimension

122.89mm × 85.04mm × 22.7mm
Weight

≈122g
Environment

Operating Temperature: -20℃～60℃ , Storage temperature: -20°C~70°C, Storage Humidity:10%～90%RH(non-condensing)
Internet

Ethernet: 2 × RJ45 (1000Mbps)
WiFi: Expand WiFi/Bluetooth module via M.2 E-KEY (2230), Supports 2.4GHz/5GHz dual-band WiFi6(802.11a/b/g/n/ac/ax) and
Bluetooth 5.2
4G: Extend 4G LTE via Mini PCIe
Usb

2 × USB3.0 (Max: 1A)
